| Model: | |
|---|---|
| Quantity: | |
U-P6090DC
UVING
8479899990
SPECIFICATION
Model | P5070DC | P6090DC |
Max.Cutting Speed | 800mm/s | |
Cutting Area | 500*700mm | 600*900mm |
Cutting Thickness | ≤1.2mm | |
Cutting Pressure | 1000g | |
Cutting Material | PET,PVC,cardboard,non-drying,film,Fiber composite materials,fabrics,pu,rubber plates,etc. | |
Blade | Dual Blades(Cutting&Creasing) | |
contour Cut | ARMS,with ccD cameraAutomatic contour cut | |
Material Fixing Mode | Vacuum adsorption | |
Working Mode | Flatbed | |
Driver | Servo motor | |
Cutting Precision | ≤0.15mm | |
Repeatable Precision | ≤0.05mm | |
Cutting Circle Diameter | 1mm | |
Interface | USB/U-Disc Port/Ethernet Port | |
Compatible Software | Signmaster,AutoCAD,Coreldraw etc | |
Instructor of the Plotter | HPGL compatible format | |
CNC Panel | Multi Language LCD touch panel | |
Machine Size | 129*87*97cm | 149*100*98cm |
Voltage | DC220V±10%，50HZ | |
